Fast EV Charging Station with Color Display
The NEDF 40–240kW floor-mounted DC fast charging pile is designed for scalable EV charging sites that need reliable output, dual-connector operation, wide DC200–1000V compatibility, and flexible customization for commercial parking, fleet, and highway charging projects.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Descriptions
Scalable DC Fast Charging Solution for EV Infrastructure Projects
The NEDF 40–240kW DC fast charging pile is developed for commercial EV charging projects that require stable performance, flexible power selection, and long-term operation. It is suitable for charging station developers, fleet operators, real estate owners, highway service areas, and public infrastructure projects.
With power configurations from 40kW to 240kW, this floor-mounted DC fast charger can be selected according to site traffic, available grid capacity, vehicle type, and investment plan. Its DC200–1000V output range helps support a wide range of electric vehicles, including mainstream passenger cars, commercial EVs, and vehicles using higher voltage battery platforms.
The standard configuration includes 2 charging connectors, while project-based designs can support up to 4 guns per unit. This helps charging operators improve equipment utilization and serve more vehicles during peak charging hours. For demanding projects, optional liquid cooling and custom cabinet designs are available.
The NEDF series is also suitable for integration with remote operation systems and energy storage charging solutions. For sites with limited transformer capacity or unstable power supply, it can be planned together with battery energy storage to reduce grid pressure and support more reliable charging service.
Key Product Advantages
Wide power coverage from 40kW to 240kW for different project scales
DC200–1000V output range for broad EV compatibility
Dual charging connectors as standard for commercial operation
Up to 4 charging guns supported for higher site throughput
AC380V ±20% input for industrial power supply environments
Air-cooled cable as standard, with optional liquid cooling design
IP54 protection for indoor and outdoor deployment
Custom design available for project branding and configuration needs
Remote operation and service support for charging station operators
Suitable Applications
EV charging station investment projects
Fleet depots for taxis, logistics vehicles, and buses
Commercial parking areas in malls, hotels, and office buildings
Highway service area charging stations
Urban public EV charging networks
Weak-grid sites with energy storage charging systems
Project Value for Charging Operators
For buyers, the value of a DC fast charging station is not only charging speed. A practical charger must match the local power supply, vehicle mix, parking layout, operating model, and future expansion plan.
The NEDF 40–240kW series gives operators a flexible product platform. A lower-power configuration can be used for sites with limited grid capacity, while 120kW to 240kW models can support higher-turnover charging locations. With dual connectors and multi-gun expansion capability, the charger helps improve station utilization and reduce waiting time for users.
Our Fast EV Charging Station
- This advanced charging solution is designed to meet the growing demands of electric vehicle (EV) charging infrastructure. With its high-power output, efficient performance, and user-friendly features, this charging station provides a comprehensive solution for both EV owners and charging operators.
- The floor-mounted design ensures stability and durability, making it ideal for installation in public areas, commercial spaces, and parking lots. Its compact footprint allows for seamless integration into existing infrastructure, maximizing space utilization and minimizing installation costs.
- With a power output of 40kW, this charging station offers fast and efficient charging, significantly reducing the charging time for EVs. It caters to the increasing demand for quick and convenient charging options, allowing EV owners to get back on the road with minimal delay.
- Equipped with dual charging ports, the station enables simultaneous charging of two vehicles. This dual-port configuration optimizes charging capacity and reduces waiting times, ensuring that more EVs can be accommodated and serviced efficiently.
- The station supports multiple charging standards, including CCS1, CCS2, Chademo, and GB/T, making it compatible with a wide range of EV models. This compatibility promotes accessibility and convenience, allowing EV owners to charge their vehicles without worrying about compatibility issues.
- Safety is paramount, and the charging station incorporates comprehensive protection mechanisms to safeguard against overcurrent, overvoltage, and temperature fluctuations. These safety features ensure reliable and secure charging operations, protecting both the EVs and the users.
- In terms of user experience, the charging station features a user-friendly interface and a clear display screen. EV owners can easily initiate charging sessions, monitor the progress, and access real-time charging information. The station also offers flexible payment options, including credit card payments, making the charging process convenient and hassle-free.
Product parameters
| Detailed specifications | Rated power | 60KW 80KW 120KW 160KW 180KW 240KW | ||
| Charging equipment | Single gun output current range | 0-200A | Installation method | Vertical |
| Wiring method | Bottom in and out | Equipment size | 1600*750*550mm | |
| Input voltage | AC380V±20% | Input frequency | 45-65Hz | |
| The output voltage | 200-1000VDC | Cable length | 5m | |
| Electrical indicators | Current limit protection value | ≥110% | Stabilization accuracy | ≤±0.5% |
| Steady flow accuracy | ≤±1% | Harmonic content THD | ≤5% (above 50% load) | |
| Effectiveness | ≥95% | Power factor | ≥0.98 (above 50% load) | |
| Feature design | HMI | 7-inch bright color touch screen | charging method | Charging by swiping/charging by password |
| Charging mode | Automatic full charge / fixed power / fixed amount / fixed time | payment method | Credit card payment/password charging | |
| Safe design | Executive standard | IEC 61851-1:2017,ICE 62196-2:2016 | Security function | Charge gun temperature detection, overvoltage protection, undervoltage protection, overload protection, short circuit protection, grounding protection, over temperature protection, low temperature protection, insulation monitoring protection, polarity reverse protection, lightning protection, emergency stop protection, leakage protection |
| Environmental indicators | Operating temperature | -20ºC~+50ºC | Protection level | IP54 |
| Working humidity | 5%~95% non-condensing frost | Cooling method | Air-cooled | |
| Working altitude | <2000m | Noise control | ≤60dB | |
Our Company
FAQ
Q: How do I know which power level is suitable for my project?
A: We usually evaluate the site power capacity, expected daily charging volume, vehicle type, parking time, and budget. For moderate commercial use, 80–120kW is commonly selected. For high-traffic public stations or fleet depots, 160–240kW is more suitable.
Q: Is this charger suitable for both passenger cars and commercial EVs?
A: Yes. With a DC200–1000V output range and 0–300A output current, the charger can serve many mainstream passenger cars and commercial electric vehicles, depending on connector configuration and vehicle charging limits.
Q: Can one charger serve more than two vehicles?
A: The standard model includes 2 charging connectors. For projects requiring higher throughput, the system can be configured to support up to 4 guns per unit.
Q: What is the main advantage of a floor-mounted charger compared with a wall-mounted model?
A: A floor-mounted charger usually supports higher power, better internal module arrangement, easier service access, and stronger suitability for commercial charging stations or fleet projects.
Q: Can the charger be installed outdoors for long-term use?
A: Yes. The charger supports indoor and outdoor installation and has IP54 protection. For harsh outdoor sites, we recommend confirming local temperature, humidity, rain exposure, and dust conditions before final configuration.
Q: What should I prepare before installation?
A: You should prepare a suitable foundation, AC380V power supply, grounding, cable routing, network connection if remote management is needed, and enough parking space for vehicle access.
Q: Does the charger support remote management?
A: Yes. Remote operation and service support are available, helping operators monitor charger status, improve maintenance efficiency, and reduce downtime.
Q: Can this charger be used with solar or battery energy storage?
A: Yes. For sites with weak grid capacity or high peak electricity costs, the charger can be integrated into an energy storage charging solution to improve power stability and reduce grid impact.
Q: What is the standard cable length?
A: The standard cable length is 5 meters. Longer cable options can be discussed according to parking layout and user operation habits.
Q: Is liquid cooling necessary for this model?
A: Air cooling is standard and suitable for many commercial projects. Liquid cooling is optional for projects with higher charging demand, higher current requirements, or stricter thermal management needs.
Q: What happens if the charger temperature becomes too high?
A: The system supports intelligent power derating when shell temperature exceeds 70°C. This helps protect internal components and maintain safe operation.
Q: Can the product appearance be customized with our brand?
A: Yes. Custom design, OEM, and ODM services are available, including cabinet color, logo, connector selection, and project-specific configuration.
Q: What charging standards can be supported?
A: The charger can be configured based on market requirements, such as GB/T, CCS1, or CCS2. The final connector standard should match the target country and vehicle models.
Q: What is the lead information needed for quotation?
A: We need the target country, required power, connector standard, number of connectors, installation environment, grid condition, quantity, communication requirements, and whether customization is needed.
Q: Is this product suitable for charging station investors?
A: Yes. Its flexible power options, dual-connector configuration, remote operation support, and commercial-grade structure make it suitable for investors building public or semi-public EV charging stations.
